1600mm Screw Driven Ground Piles Photovoltaic Installation PV Solar Panel

Name: 1600mm Screw Driven Ground Piles Photovoltaic Installation PV Solar Panel
Brand: TIANFON
Price: 800 USD

1600mm Screw Driven Ground Piles Photovoltaic Installation PV Solar Panel Manufactures

Brand Name : TIANFON

Model Number : Ground Screw Piles

Certification : SGS,ISO 9001,ISO 14001,OHSAS 18000

Place of Origin : CHINA

MOQ : 5 set

Price : USD800-2000/set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30MW/month

Delivery Time : 15-25 work days

Packaging Details : standard export packing

Type : on/off grid

Size : as required

Wind Load : 60m/s

Snow Load : 1.4KN/㎡

Feature : Easy & Quick Installation

Engineering Service : Acceptable

Contact Now

Photovoltaic Installation PV Panel Ground Screw 1600mm Helical Piles Foundation

The ground screw & anchor are designed and engineered for each customer's site-specific conditions to minimize the field installation labor and require no field welding, drilling, or other on-site fabrication.

It is the intelligent alternative fixing method for all types of installations requiring a solid footing. Tests conducted in different consistency soil showed a clear advantage in all aspects, from wind loads and lateral pull, to horizontal load and lift, compared to concrete footings which are held in the ground mostly by their own weight.

Product feature:

• Install site: All types of Soil
• Pipe Material: Steel Q235B
• Pipe Diameters: 76 mm~200 mm
• Pipe Length: 500~2500 mm

• Pipe Thickness: 3~3.5mm
• Anticorrosive: High-class hot dip galvanized
• Warranty: 10 years warranty
• Duration: More than 20 years

Name	Size(mm)	Thickness(mm)	Material	Surface treatment	Photo
Piles with flange	φ 76/89,1000-2000mm(Length)	4	Q235B	Hot-Dip Galvanizing
Piles without flange	φ 76/89,1000-2000mm(Length)	4	Q235B	Hot-Dip Galvanizing
Steel pipe piles	φ 76/89,1000-2000mm(Length)	4	Q236B	Hot-Dip Galvanizing

Products can be customized according to customer requirement.

1600mm Screw Driven Ground Piles Photovoltaic Installation PV Solar Panel

Product Tags:

screw driven ground piles

foundation screw anchors
